Thomas Wire Die - Die Inserts

Insert #	Standard Nib		Maximum Recommended Hole Size	Standard Casing
	Diameter	Height		Diameter	Height

R-2

0.325

0.330

0.128

1" or 1/2"

.9/16

R-5

0.625

0.600

0.280

1 1/2

7/8

R-6

0.710

0.700

0.350

2

1 1/8

R-8

1.000

0.820

0.516

3

1 3/4

R-9

1.187

0.820

0.687

3

1 3/4

R-10

1.500

1.000

0.875

3 or 4

2

R-11

1.830

1.250

1.250

4

2 1/4

R-12

2.185

1.375

1.600

4

2 3/8

R-14

2.560

1.375

1.750

6 or 7

2 1/2

R-15

3.000

1.375

2.250

6 or 7

2 1/2

R-16

3.500

1.375

2.500

6 or 7

2 1/2

R-17

4.000

1.500

3.000

9

3

R-18

5.500

2.125

3.750

11

4 1/2

R-19

6.500

2.125

4.500

13

4 1/2
